# T-connector

## **Exterior**

![](https://498068148-files.gitbook.io/~/files/v0/b/gitbook-legacy-files/o/assets%2F-M7fZsO11LItbPHrVN6W%2F-M7f_TuZUIGjiNsFn4zu%2F-M7fcESe6PCy15wvfSbb%2FT-connector%20Definition-en.jpg?alt=media\&token=8d070ef3-f156-41fc-ad4e-bdbf52427f4f)

## Package contains

Besides other agreements, our standard package contains:

* T-connector \* 1

Union standard package contains

* Union nuts \* 2
* Union adapter \* 2
* Union O-ring \* 2

T-connector is generally shipped with a paddle set.

## Size, material, model

| Parts             | Material                            |
| ----------------- | ----------------------------------- |
| T-connector       | UPVC, PPH or PVDF (for order made) |
| Nuts              | UPVC, PPH or PVDF (for order made) |
| Union adapter     | UPVC, PPH or PVDF (for order made) |
| Paddle set screws | Stainless steel 304                 |
| O-ring            | EPDM、VITON、FEPM (for order made)    |

## UPVC pipe - union diameter size(mm)

<figure><img src="https://498068148-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F-M7fZsO11LItbPHrVN6W%2Fuploads%2FoId3LXyuhKEe4V08oLXn%2Fpaddle-wheel-flowmeter-union-size.png?alt=media&#x26;token=45ef923f-8c4c-45e8-bb90-d71afa554eca" alt=""><figcaption></figcaption></figure>

<table data-header-hidden><thead><tr><th></th><th width="134">A</th><th>B</th><th>C</th><th>D</th><th>E</th><th>F</th><th>G</th><th>H</th></tr></thead><tbody><tr><td></td><td>A</td><td>B</td><td>C</td><td>D</td><td>E</td><td>F</td><td>G</td><td>H</td></tr><tr><td>½"</td><td>164</td><td>100</td><td>27.6</td><td>36</td><td>62.3</td><td>46.2</td><td>115.7</td><td>82.2</td></tr><tr><td>¾"</td><td>168</td><td>100</td><td>32.6</td><td>41.9</td><td>60</td><td>50.5</td><td>115.7</td><td>85.7</td></tr><tr><td>1"</td><td>168</td><td>100</td><td>40.6</td><td>50</td><td>60</td><td>60</td><td>115.7</td><td>85.7</td></tr><tr><td>1¼"</td><td>210</td><td>114</td><td>50.2</td><td>59.6</td><td>65</td><td>75.6</td><td>127</td><td>89.2</td></tr><tr><td>1½"</td><td>218</td><td>120</td><td>56</td><td>65.7</td><td>70</td><td>83</td><td>134</td><td>92.5</td></tr><tr><td>2"</td><td>269.5</td><td>133.3</td><td>72</td><td>81</td><td>81</td><td>99.7</td><td>148.8</td><td>99</td></tr></tbody></table>

## UPVC pipe - spigot pipe diameter size(mm)

<figure><img src="https://498068148-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F-M7fZsO11LItbPHrVN6W%2Fuploads%2Fof0au71hWRoieXfMq0P8%2Fpaddle-wheel-flowmeter-spigot-size.png?alt=media&#x26;token=e02f29e6-1134-4d23-9377-0e16a87722d8" alt=""><figcaption></figcaption></figure>

<table data-header-hidden><thead><tr><th></th><th width="52">A</th><th>B</th><th>C</th><th>D</th><th>E</th><th>F</th></tr></thead><tbody><tr><td></td><td>A</td><td>B</td><td>C</td><td>D</td><td>E</td><td>F</td></tr><tr><td>2½"</td><td>160</td><td>70</td><td>76</td><td>92</td><td>106.5</td><td>152.5</td></tr></tbody></table>

## Device size(mm)

<figure><img src="https://498068148-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F-M7fZsO11LItbPHrVN6W%2Fuploads%2FeydR8qxRuhvjR8pbOeR7%2Fpaddle-wheel-flowmeter-device-size.png?alt=media&#x26;token=76087154-bbef-4404-a08a-8bb136b3a811" alt=""><figcaption></figcaption></figure>

| I  | J  |
| -- | -- |
| 63 | 63 |

## **Pulse signal and flow conversion**

UPVC T-connector

| Pipe diameter | Model   | Metric ratio (pulses per litre) | US Gallon (pulses per US gal) | UK Gallon (pulses per UK gal) |
| ------------- | ------- | ------------------------------- | ----------------------------- | ----------------------------- |
| 3/4"          | FP-P020 | 67.23                           | 254.48                        | 305.62                        |
| 1"            | FP-P025 | 53.33                           | 201.89                        | 242.46                        |
| 1-1/4"        | FP-P032 | 24.44                           | 92.51                         | 111.11                        |
| 1-1/2"        | FP-P040 | 17.02                           | 64.43                         | 77.38                         |
| 2"            | FP-P050 | 9.86                            | 37.31                         | 44.81                         |
| 2-1/2"        | FP-P065 | 5.42                            | 20.52                         | 24.64                         |

If you can not see the pipe model you are currently using in the list or have other compatibility requirements, please ask our sales representative.
