  1. Exterior, Spec, Model

Paddle set

PreviousDeviceNextT-connector

Last updated 26 days ago

Exterior

Shipping Contents

Unless otherwise specified in the purchase agreement, the standard shipment includes the following components:

  • Paddlewheel assembly (including rotor housing, paddlewheel, and axle) × 1

  • M4 mounting screws for paddlewheel assembly × 4

  • Rotor housing O-ring × 1

The paddlewheel assembly can be ordered separately or supplied together with the tee fitting.

Note: The dimensions of individual components (such as the sealing O-ring) directly affect measurement accuracy. To ensure reliable flow measurement results, only use genuine parts supplied by the manufacturer.
